??RG10D 75m two-story platform escape device configuration table |
| No. |
Note |
Specification |
Number |
Tip |
| 1 |
Descent |
RG10D 75M |
1 |
pcs |
Including Ф5×75m high-strength galvanized up and down rope |
| 2 |
Guide rope galvanized steel wire rope |
Ф10×75M |
2 |
pcs |
High-strength galvanized steel wire rope |
| 3 |
Suspension body |
|
1 |
pcs |
Protect the descender and connect the derrick and guide rope |
| 4 |
Manual controller |
ABS12 |
2 |
pcs |
Special copper alloy stainless steel material |
| 5 |
Fixed rope (galvanized steel wire rope) |
Ф12×2M |
1 |
pcs |
Maximum tensile strength: 5.2T |
| 6 |
High strength bolt with M24 nut |
M24X150 |
2 |
pcs |
Ground anchor supporting |
| 7 |
M16 stainless steel flange screws (circle to circle) |
M16 |
2 |
pcs |
Adjust the tightness of the guide rope |
| 8 |
510-10 stainless steel wire rope clamp (with lock nut) |
510-10 |
6 |
pcs |
Fixed guide rope |
| 9 |
840-10 collar (stainless steel U-shaped) |
840-10 |
2 |
pcs |
Protection guide rope |
| 10 |
Ground anchor 1.2M |
|
2 |
pcs |
Fixed ground and guide rope |
| 11 |
Multifunctional safety belt (Optional) |
MKA21 |
1 |
pcs |
Comply with European EN361/EN358 standards |
